Shock Material Rotary Slip Ring Joint Electrical Connector

Name: Shock Material Rotary Slip Ring Joint Electrical Connector
Brand: JINPAT
Price: 1 USD

Wholesale Shock Material Rotary Slip Ring Joint Electrical Connector from china suppliers

Brand Name : JINPAT

Model Number : LPC-06B

Certification : ISO9001.ISO14000.CE.UL.FCC.RoHS

Place of Origin : China

MOQ : 1PCS

Price : Negotiable

Payment Terms : TT/CC/Paypal

Supply Ability : 100K units/week

Delivery Time : 2 weeks ARO

Packaging Details : Standard/On Request

Optional : Rotating speed

Contact Material : Gold -Gold

typical application : Rotary table

Features : Very low contact resistance

Contact Now

The LPC-06B capsule slip ring can be used in any electromechanical system that requires unrestrained, continuous rotation while transferring power or data from a stationary part to a rotating part.

The LPC-06B unit is a standard, off-the-shelf unit that uses gold contacts at the rotary interface. Color-coded lead wires are used on both the stator and rotor for simplifying electrical connections.

LPC-06B Slip Ring parameter

Protection Grade	IP54
Working Speed	300 RPM
Circuits	6
Current Rating	2A Or higher
Voltage	240VAC
Working Temperature	-40~+80℃
Electric shock material	Gold to Gold
Wire specification	AWG28#, silver plated , UL
Lead Wire Length	Rotor:250mm; Stator:250mm
Insulation	1000MΩ@500VDC
Dielectric Strength	/
Electrical noise	/

LPC-06B Slip Ring Outline Drawing

Shock Material Rotary Slip Ring Joint Electrical Connector

Product Image
